Solarix Solar Charge Controller Mppt 12v / 24v 30a

Description

Product Overview

This Solarix Solar Charge Controller archives Maximum power of the solar panel: 30A (Automatically switches between 12V and 24V) this controller-regulator is designed for charging batteries through a solar panel. When the battery voltage is not sufficient, the controller plays a protective role, preventing the voltage from falling below that required to charge the battery.

Product Features

• Humanization LCD Display
• MPPT 4 Stage charging
• Load working mode optional
• Light sensor and timer programmable
• Battery type flood, lead-acid, GEL, Lithium optional
• Charge and discharge current display
• Overall Effective protection

Specifications

Stock Code: SOLMPPT122430

Description: Solarix Solar Charge Controller MPPT 12V / 24V 30A

Type: MPPT

System Voltage: 12V/24Auto

Solar Panel Maximum Voltage Voc: 100V

Maximum Open Voltage: 55V – 100V

Maximum Output Current: 30A

Solar Panel Power: 390W (12V), 780W (24V)

Battery voltage: 12V-24V

Battery Voltage Range: 8-32V

Battery type: lead acid (sealed, gel) and lithium (also can be customized for different types of batteries)

Waterproof level: IP30

Standby power consumption: 8mA (12V), 12mA (24V)

Overload protection: <10S
